Satellite
Programs Receiving and Descrambling
4-frequency DVB-S2 Demodulation
Receiving Card (C545) is an EMR IRD
function card, one card can
demodulate 4 FTA or scrambled
satellite frequencies. One EMR
maximum supports 24 FTA or scrambled
satellite frequencies.
DVB-S2
Demodulation & Descrambling Card
(C525CI) can not only be used to
descramble any scrambled programs by
two CAMs from any input cards and
also receive all the satellite
programs. One EMR maximum supports
12 CAM cards to descramble from any
inputs cards.
Local
program encoding
H.264 Digital Encoding Card
(C150D) can encode 2 digital HD/SD
programs as maximum 12 HD/SD
programs H.264 Digital Encoding in
one chassis.
H.264 Analog
Encoding Card (C150A) can encode 2
analog programs as maximum 12 HD/SD
programs H.264 Digital Encoding in
one chassis.
Using C150A
and C150D can encode all the local
programs.
Re-multiplexing & Scrambling
All the programs can be
de-multiplexed and re-multiplexed
via back board fixed on EMR, then be
sent from the EMR to the network via
multicast UDP.
There is
scrambling card in EMR3.0 chassis,
connecting to CAS for pay TV
solution.
DVB-S/S2
Modulating
DVB-S/S2 Modulation Card (C507S)
can modulate 1 frequency. Select the
right amount of C507S for DVB-S/S2
Modulation.
|
